cforce 520

UNBEATABLE VALUE
With refinements across the board, the new-generation CFORCE 520 is not only stronger and lighter but has less vibration, a tighter turning circle, is more comfortable, has a smorgasbord of user-friendly attributes, and now available in a no-frills package at an unbeatable price for a 500cc ATV. Introducing the CFORCE 520 in Hunter Green livery.

ENGINE & TRANSMISSION
Engine type: Four-stroke single-cylinder
Displacement: 495cc
Maximum power: 38hp at 7,000rpm
Maximum torque: 39Nm at 5,750rpm
Fuel system: Bosch EFI
Transmission: CVT with engine braking
Drive: H-L-N-R-Park
4WD: 2WD/4WD with locking front differential
Rear differential: Fixed

SUSPENSION & BRAKES
Suspension: Double A-Arm, independent
Brakes: Hydraulic disc brakes

WHEELS & TYRES
Wheels: 12-inch steel
Tyres: 25-inch 6-ply CST

DIMENSIONS
L x W x H: 2046 x 1125 x 1162mm
Wheelbase: 1260mm
Ground clearance: 262mm
Wet weight: 351kg

LOAD
Towing capacity: 612kg
Carrying capacity: 30kg front/60kg rear
Payload capacity: 240kg
Person: One
Fuel capacity: 17lt

FEATURES
Colour: Hunter Green
Warranty: Two years
Tow pack, horn, lights and mirrors: Yes
