uforce 800 eps XL

MIDDLEWEIGHT 800
Introducing a new middleweight XL model to the range, the UFORCE 800 EPS XL.

Based on the popular UFORCE 600 platform, the chassis has been extended and beefed up – including new suspension, steering components and greater ground clearance to accommodate the longer wheelbase. The result is a new mid-sized 4-seater UTV powered by CFMOTO’s 800cc V-twin engine and featuring an all-new CFMOTO CVT system – smoother driving, easier working.

The new middleweight XL model adds to the growing ‘crew’ range now customers have the choice of three attractive model offerings from CFMOTO.

ENGINE
Engine type: V-twin, liquid cooled, 4-stroke, SOHC, 8-valve
Displacement: 800cc
Maximum power: 63hp at 7,000rpm
Maximum torque: 69.8Nm at 5,500rpm
Fuel system: Bosch EFI with two power modes NORMAL or WORK
Transmission: CFMOTO CVT
Drive: H-L-N-R-Park
4WD: 2WD/4WD
Differential: Fixed rear differential
Downhill Assist: Electronic assist hill descent control (DAC)
Steering: Power steering (EPS)

CHASSIS
Suspension front: Dual A-arm, with 225mm of travel
Suspension rear: Dual A-arm, with 225mm of travel
Shock absorber: Shock absorbers with compression/rebound adjustment
Brakes: All four hydraulic disc brakes
Wheels: 14-inch alloy rims
Tyres: 27-inch tyres

SIZE
Dimensions (L/W/H): 3640 x 1525 x 2007mm
Cargo tray (D/W/H): 870 x 1300 x 275mm
Wheelbase: 2770mm
Ground clearance: 300mm
Wet weight: 775kg

LOAD
Towing capacity: 680kg
Cargo tray capacity: 300kg
Roll Cage: ROPS-certified
Fuel Capacity: 40L
Persons: Four

OTHER
Colours: Twilight Blue
Winch: 4500lb with nylon rope
Warranty: Two Year Warranty
