zforce 1000 eps sport r

SPORT R
All the fun of the ZFORCE 1000 SPORT, and then more.

Introducing the ZFORCE 1000 SPORT R. The SPORT R gets more power (up 10hp), improved dynamic suspension, colour-matched beadlock rims with big 29-inch Stag tyres, new sports steering, sports seats, an updated five-inch display with CFMOTO Ride App connectivity, and a 3500lb nylon rope winch.

ENGINE & TRANSMISSION

Engine type: Liquid-cooled, fuel-injected, four-stroke V-twin
Displacement: 963cc
Maximum power: 90hp at 7,500rpm
Maximum torque: 87Nm at 6,750rpm
Fuel system: Bosch EFI with 'fly by wire'
Transmission: CVT
Drive: H-L-N-R-Park plus handbrake
4WD: 2WD/4WD with locking front differential
Rear differential: Limited-slip
Steering: Power

SUSPENSION & BRAKES

Front: Dual A-Arm independent with sway bar, 340mm travel
Rear: Multi-link independent with sway bar, 380mm travel
Shocks: Gas shock with high / low-speed compression and rebound damping setting,
rear shock with dual-spring
Brakes: Four-wheel hydraulic disc brakes

WHEELS & TYRES

Wheels: 14-inch alloy colour matched beadlock rims
Tyres: 29-inch 8-ply CST Stag

DIMENSIONS

L x W x H: 3020 x 1635 x 1850mm
Wheelbase: 2285mm
Ground clearance: 340mm
Wet weight: 705kg

LOAD

Towing capacity: 400kg
Rear cargo capacity: 100kg
Payload capacity: 350kg
Persons: Two
Fuel capacity: 36.5lt

HIGHLIGHTS

90hp V-twin engine: Yes
Sport seats: Yes
Sport steering wheel: Yes
Beadlock rims: Yes
Winch: Yes, 3500lb with nylon rope
LED Headlights: Yes
Display: Five-inch colour digital display
CFMOTO Ride App: Yes
Roof kit: Yes

OTHER

Roll cage: ROPS-certified
Warranty: 12 months
Colours: Royal Blue
